蓄电池系列
|
电池型号 |
额定 电压( V ) |
20小时率 容量( AH ) |
外部尺寸(mm) | 参考重量(Kg) | |||
|
长 |
宽 |
高 |
总高 | ||||
| CB3.2-6 | 6 | 3.2 | 134.0 | 34.0 | 62.0 | 67.0 | 0.58 |
| CB8-6 | 6 | 8 | 151.0 | 50.0 | 94.0 | 100.0 | 1.35 |
| CB3-6 | 6 | 3 | 43 | 48 | 85 | 85 | 0.45 |
| CB5-6F | 6 | 5 | 66 | 66 | 96 | 103 | 0.86 |
| CB5-6S | 6 | 5 | 66 | 66 | 96 | 116 | 0.86 |
| CB8.5-6 | 6 | 8.5 | 98.0 | 56.5 | 118.0 | 118.0 | 1.50 |
| CB1.3-6 | 6 | 1.3 | 97.0 | 24.0 | 52.0 | 58.0 | 0.29 |
| CB2.3-6 | 6 | 2.3 | 43.0 | 37.0 | 76.0 | 76.0 | 0.32 |
| CB14-6 | 6 | 14 | 108.0 | 71.0 | 140.0 | 140.0 | 2.30 |
| CB2.8-6 | 6 | 2.8 | 66.0 | 34.0 | 100.0 | 106.0 | 0.60 |
| CB4-6 | 6 | 4 | 70.0 | 47.0 | 101.0 | 106.0 | 0.68 |
| CB4.5-6 | 6 | 4.5 | 70.0 | 47.0 | 101.0 | 106.0 | 0.70 |
| CB7-6 | 6 | 7 | 151.0 | 34.0 | 94.0 | 100.0 | 1.07 |
| CB10-6 | 6 | 10 | 151.0 | 50.0 | 93.5 | 99.5 | 1.65 |
| CB12-6 | 6 | 12 | 151.0 | 50.0 | 93.5 | 99.5 | 1.90 |
| CB1-6 | 6 | 1 | 51.0 | 42.0 | 51.0 | 56.0 | 0.24 |
| CB5-6 | 6 | 5 | 70 | 47 | 101 | 106 | 0.75 |
| CB7.5-6 | 6 | 7.5 | 151.0 | 34.0 | 94.0 | 100.0 | 1.20 |
| CB2.8-6B | 6 | 2.8 | 105.5 | 42.0 | 69.0 | 69.0 | 0.60 |
